John Deere harvester heads are renowned for their productivity. Thanks to their advanced design, hydraulics and automation, they offer excellent performance, measurement accuracy and delimbing quality. The robust design ensures durability, and the user-friendly control system provides unrivalled controllability. Daily maintenance is easy and can usually be carried out without having to change the position of the harvester head.
Our selection includes harvester heads for all felling needs, from early thinning to regeneration harvesting and from softwood to hardwood. With a wide range of optional equipment, the harvester head can be equipped to suit every logging site. The most popular optional equipment include grease lubrication, mass treatment, colour marking equipment and a top saw.
A high-performance combination
John Deere harvester heads work seamlessly with John Deere harvesters. The technical features of the combination are fine-tuned to serve productivity: efficient felling, smooth handling and highly accurate measurement.
- Compatible: 1070G, 1170G, 1270H
- Feed roller opening: 640 mm
- Maximum cutting diameter: 620 mm
- Saw bar length, max: 750mm
- Feed speed, max: 6.0 m/s
- Feed force, max: 22 – 27 kN
- Weight: 1105 kg
- Compatible: 1270H, 1470H
- Feed roller opening: 680 mm
- Maximum cutting diameter: 710 mm, 750 mm
- Saw bar length, max: 900mm
- Feed speed, max: 6.0 m/s
- Feed force, max 25 – 42 kN
- Weight: H425: 1360 kg, H425HD: 1399 kg
- Compatible: 1270H, 1470H
- Feed roller opening: 720 mm
- Maximum cutting diameter: 760 mm
- Saw bar length, max: 900mm
- Feed speed, max: 5.9 m/s
- Feed force, max 40 – 43 kN
- Weight 1650 kg
- Compatible: 1270H, 1470H
- Feed roller opening: 700 mm
- Maximum cutting diameter: 750 mm
- Saw bar length, max: 900mm
- Feed speed, max: 6.4 m/s
- Feed force, max: 30 – 41 kN
- Weight: 1495 kg
- Compatible: 1470H
- Feed roller opening: 760 mm
- Maximum cutting diameter: 750 mm
- Saw bar length, max: 900mm
- Feed speed, max: 6.0 m/s
- Feed force, max: 28 – 42 kN
- Weight: 1930 kg
- Compatible: 1270H, 1470H
- Feed roller opening: 550 mm
- Maximum cutting diameter: 550 mm
- Saw bar length, max: 670mm
- Feed speed, max: 5.0 m/s
- Feed force, max: 27 – 30 kN
- Weight: 1690 kg
- Compatible: 1470G, 1470H
- Feed roller opening: 685 mm
- Maximum cutting diameter: 660 mm
- Saw bar length, max: 550mm
- Weight: 1800 kg
